Notifier AFP-2800 Operator's Manual

AFP-2800 - Fire Indicator Panel – Appendix Page 71
© N
OTIFIER
I
NERTIA
P
TY
L
TD
, 2001
WWW
.
INERTIA
.
COM
.
AU
5.7
5.75.7
5.7 F
FF
F
LASH
LASHLASH
LASH
S
SS
S
CAN
CANCAN
CAN



D
DD
D
ETECTOR
ETECTOR ETECTOR
ETECTOR
S
SS
S
ENSITIVITIES
ENSITIVITIESENSITIVITIES
ENSITIVITIES
FlashScan Detectors Sensitivity Settings Table
Detector Type Alarm
%/Metre Obscuration
Pre-Alarm
%/Metre Obscuration
Photo Optical
Level 1 1.64% Auto
Level 2 2.40% 0.98%
Level 3 3.15% 1.54%
Level 4 3.90% 2.10%
Level 5 4.69% 2.66%
Level 6 5.45% 3.25%
Level 7 6.20% 3.81%
Note 1, 2
Level 8 6.96% 4.36%
Level 9 7.71% 4.92%
Ionisation
Level 1 1.64% Auto
Level 2 2.46% 1.31%
Level 3 3.28% 1.64%
Level 4 4.10% 2.46%
Level 5 4.92% 3.28%
Level 6 5.74% 4.10%
Level 7 6.56% 4.92%
Note 1, 2
Level 8 7.38% 5.74%
Level 9 8.20% 6.56%
View Detector
Level 1 0.09% Auto
Level 2 0.16% 0.07%
Level 3 0.33% 0.10%
Level 4 0.66% 0.16%
Level 5 0.98% 0.33%
Level 6 1.64% 0.66%
Level 7 2.30% 0.98%
Note 1, 2
Level 8 2.62% 1.31%
Level 9 3.28% 1.64%
Acclimate
Level 1 1.625% 1.625%
Level 2 3.25% 1.625%
Level 3 3.25 – 6.5% Auto 1.625 – 3.25% Auto
Level 4 6.5 % 3.25 %
Level 5 6.5 – 9.75% Auto 3.25 - 6.5% Auto
Level 6 9.75% 6.5%
Level 7 9.75 - 13.0% Auto 6.5 - 9.75% Auto
Note 1, 2
Level 8 13.0% 9.75%
Level 9 Not available Not available
Thermal Degrees Celsius
Level 1 43
O
C
Note 2
Level 2 57
O
C
Note 1
Level 3 65
O
C
Level 4 70
O
C
Level 5 75
O
C
Level 6 88
O
C
Note 1 = Default setting on normal program
Note 2 = Default setting on auto program
