Page 22 AFP-2800 - Fire Indicator Panel – Panel Operation
© N
OTIFIER
I
NERTIA
P
TY
L
TD
, 2001
WWW
.
INERTIA
.
COM
.
AU
4.3.3.1
4.3.3.14.3.3.1
4.3.3.1 S
SS
S
ERVICE
ERVICE ERVICE
ERVICE
M
MM
M
ENU
ENU ENU
ENU
- L
- L- L
- L
IST
IST IST
IST
- A
- A- A
- A
LARM
LARMLARM
LARM
This screen will display all individual alarm conditions active at the time. As new alarms (unacknowledged) force
the panel into Fire Fighters mode, this page can only be accessed once all alarms are acknowledged.
Counters will continue to dynamically update while in this screen.
INDIVIDUAL POINT ALARM LIST
01 OCT 1999 14:44:37
RESETACKNNEXTPREV ISOL
TIME TYPE STATUS NUMBER
01 OCT 14:01 SMOKE ACKD ALARM 1 OF 2
L1D1 PENTHOUSE
01 OCT
01 OCT 01 OCT
01 OCT 14:40 HEAT ACKD ALARM 2 OF 2
14:40 HEAT ACKD ALARM 2 OF 214:40 HEAT ACKD ALARM 2 OF 2
14:40 HEAT ACKD ALARM 2 OF 2
1.10.Z1 NORTH STAIRWELL
1.10.Z1 NORTH STAIRWELL1.10.Z1 NORTH STAIRWELL
1.10.Z1 NORTH STAIRWELL
A = 0
F = 2
I = 0
N = 0
Actions:
Use the PREV
and NEXT buttons to scroll through
the active Alarms.
Use ACKN
to acknowledge currently highlighted alarm.
Use RESET
to reset the currently highlighted alarm.
You will be asked to press ACKN
to confirm, press any
other button to abort.
Use ISOL
to isolate the currently highlighted alarm.
You will be asked to press ACKN
to confirm, press any
other button to abort.
4.3.3.2
4.3.3.24.3.3.2
4.3.3.2 S
SS
S
ERVICE
ERVICE ERVICE
ERVICE
M
MM
M
ENU
ENU ENU
ENU
- L
- L- L
- L
IST
IST IST
IST
- F
- F- F
- F
AULT
AULTAULT
AULT
This list will display all system faults in chronological order. If faults are set as non latching, they will self clear from
this list. If faults are set to latching, a reset action from this list is the only way to clear them. Once a fault is
isolated it remains in the fault list but does not operate the fault outputs.
FAULT LIST
01 OCT 1999 14:44:37
RESETACKNNEXTPREV ISOL
TIME TYPE STATUS NUMBER
01 OCT 10:00 SMOKE FAULT 1 OF 2
L1D1 PENTHOUSE
01 OCT 12:15 HEAT ISOL FAULT 2 OF 2
1.10.Z1 STAIRWELL
A = 0
F = 2
I = 0
N = 0
Actions:
Use the PREV
and NEXT buttons to scroll through
the faults.
Use ACKN
to acknowledge currently highlighted fault;.
Use RESET
to reset the currently highlighted fault.
You will be asked to press ACKN
to confirm, press any
other button to abort.
Use ISOL
to isolate the currently highlighted fault.
You will be asked to press ACKN
to confirm, press any
other button to abort.
Note: You can also use the arrow keys, the Page Up and Page Dn keys on an external keyboard for scrolling functions.
