4.3.3.3
4.3.3.34.3.3.3
4.3.3.3 S
SS
S
ERVICE
ERVICE ERVICE
ERVICE
M
MM
M
ENU
ENU ENU
ENU
- L
- L- L
- L
IST
IST IST
IST
- I
- I- I
- I
SOLATED
SOLATEDSOLATED
SOLATED
This will display any isolation conditions active at the time.
ISOLATE LIST
01 OCT 1999 14:44:37
DEISOLNEXTPREV MENU
TIME TYPE STATUS NUMBER
01 OCT 10:00 SMOKE ISOL 1 OF 2
L1D1 PENTHOUSE
01 OCT
01 OCT 01 OCT
01 OCT 12:15 HEAT ISOL FAULT 2 OF 2
12:15 HEAT ISOL FAULT 2 OF 212:15 HEAT ISOL FAULT 2 OF 2
12:15 HEAT ISOL FAULT 2 OF 2
1.10.Z1 STAIRWELL
1.10.Z1 STAIRWELL1.10.Z1 STAIRWELL
1.10.Z1 STAIRWELL
A = 0
F = 0
I = 2
N = 0
Actions:
Use the PREV
and NEXT buttons to scroll through
the Isolated points.
Use DEISOL
to De-Isolate the currently highlighted
isolated point.
Press MENU
to return to the Service menu
Note: You can also use the arrow keys, the Page Up and Page Dn keys on an external keyboard for scrolling functions.
4.3.3.4
4.3.3.44.3.3.4
4.3.3.4 S
SS
S
ERVICE
ERVICE ERVICE
ERVICE
M
MM
M
ENU
ENU ENU
ENU
- L
- L- L
- L
IST
IST IST
IST
- A
- A- A
- A
CTIVE
CTIVECTIVE
CTIVE
This list will display all non-alarm AZF’s that are currently active. If points are set as latching, this is where they will
need to be manually reset. If points are non-latching, they will self-clear.
ACTIVE LIST
01 OCT 1999 14:44:37
RESETACKNNEXTPREV ISOL
TIME TYPE STATUS NUMBER
01 OCT 10:00 SMOKE ACTIVE 1 OF 2
L1D1 PENTHOUSE
01 OCT 12:15 HEAT ISOL ACTIVE 2 OF 2
1.10.Z1 STAIRWELL
A = 0
F = 0
I = 0
N = 2
Actions:
Use the PREV
and NEXT buttons to scroll through
the active Non-Alarm AZF.
Use ACKN
to acknowledge currently highlighted active
Non-Alarm AZF.
Use RESET
to reset the currently highlighted active
Non-Alarm AZF.
You will be asked to press ACKN
to confirm, press any
other button to abort.
Use ISOL
to isolate the currently highlighted active
Non-Alarm AZF.
You will be asked to press ACKN
to confirm, press any
other button to abort.
Note: You can also use the arrow keys, the Page Up and Page Dn keys on an external keyboard for scrolling functions.
