AFP-2800 - Fire Indicator Panel – System Description Page 13
©
N
OTIFIER
I
NERTIA
P
TY
L
TD
,
2001
WWW
.
INERTIA
.
COM
.
AU
FlashScan
Loops
Item Description Notes
LCM FlashScan
Loop Controller
Loops 1,3,5,7,9
Max 5 per system
LEM FlashScan
Loop Controller
Loops 2,4,6,8,10
Max 5 per system, LEM
“piggybacks” onto LCM.
Annunciators
Item Description Notes
ACM32 Annunciator 32 Red LED
ACM16AT Annunciator 16 Pushbutton
16 Red LED
16 Yellow LED
SCS-8 Annunciator 8 x 3 Position switches
8 x Red LED
8 x Yellow LED
8 x Green LED
A maximum of 99
Annunciators can be
installed on
communication ring #1.
LDM-R32 Annunciator 32 x 1 Amp relay outputs
Field Modules
Item Description Notes
AZM-8 8 AZF inputs
4 Programmable Relay Outputs
PAZM-8 8 AZF Inputs with programmable end
of line resistor values (1k5 to 5K6)
Fan Controller 3 Inputs (Opto-isolated, not monitored)
3 Programmable outputs
A maximum of 100 field
modules can be installed
on communications ring
#1 and 100 on
communications ring #2.
On board power supply
accommodates for the
first 10 modules. Larger
power supplies and
separate feeds are
required for systems
with additional modules.
RS485 signal is
regenerated at each
field module.
Display Interfaces
Item Description Notes
LCD-80 Terminal mode display interface A maximum of 30
Display Interfaces can
be installed on
communications ring #1.
