This is the base level of service menu mode.
Screen functions such as the selection of a menu item may be selected in two ways.
1. By using the soft UP
or DOWN buttons to scroll to the required item, then pressing SELECT or
2. By selecting the menu item number on the keypad.
The top right corner of the screen shows a quick system status, giving the total number of alarms, faults, isolates
and Non-Alarm events at any given time.
Pressing the SERVICE MENU
button at any time will return you to this main menu screen
1) LIST LIST SYSTEM INFORMATION
2) ISOLATE ISOLATE MENU
3) CONFIG CONFIGURE POINTS
4) FLASHSCAN FLASHSCAN UTILITIES
5) TEST TEST MODULE FUNCTIONS
6) GLOBAL CONFIGURE GLOBAL PARAMETERS
7) DIAG VARIOUS DIAGNOSTIC TESTS
8) PRINT VARIOUS PRINTING UTILITIES
9) LOG-OFF RESET PASSWORD TIMER
SERVICE MENU
01 OCT 1999 14:44:37
SELECTDOWNUP MENU
USE BUTTONS/NUMBERS TO SELECT A FUNCTION
A = 0
F = 0
I = 0
N = 0
Action:
• Use UP
and DOWN buttons to scroll through
options (or button 1
to 9 from keypad)
• Use SELECT
to select the currently highlighted
option
