AFP-2800 - Fire Indicator Panel – Panel Operation Page 21
©
N
OTIFIER
I
NERTIA
P
TY
L
TD
,
2001
WWW
.
INERTIA
.
COM
.
AU
4
44
4
4
44
4
.
..
.
.
..
.
3
33
3
3
33
3
.
..
.
.
..
.
3
33
3
3
33
3
S
SS
S
S
SS
S
E
EE
E
E
EE
E
R
RR
R
R
RR
R
V
VV
V
V
VV
V
I
II
I
I
II
I
C
CC
C
C
CC
C
E
EE
E
E
EE
E
M
MM
M
M
MM
M
E
EE
E
E
EE
E
N
NN
N
N
NN
N
U
UU
U
U
UU
U
-
--
-
-
--
-
L
LL
L
L
LL
L
I
II
I
I
II
I
S
SS
S
S
SS
S
T
TT
T
T
TT
T
These menus allow access to various information lists. List Menu 1 is shown first. Use the PREV and NEXT
buttons to scroll through the options then use SELECT to select the currently highlighted option or use the
numeric keypad. Item 5 on List Menu 1 (LIST) will move you to List Menu 2. The MENU
button will return you to
the Service Menu. The available lists are:
1) ALARM DISPLAY ALARMS
2)
FAULT DISPLAY FAULTS
3) ISOLATED DISPLAY ISOLATES
4) ACTIVE DISPLAY ACTIVE NON-ALARM AZF’S
5)
LIST ZONES, POINT TYPES AND FLASHSCAN
LIST MENU 1
01 OCT 1999 14:44:37
DOWNUP
MENU
USE BUTTONS/NUMBERS TO SELECT A FUNCTION
A = 0
F = 0
I = 0
N = 0
SELECT
1) ZONE DISPLAY ZONE GROUPS
2)
FLASHSCAN DISPLAY FLASHSCAN INFORMATION
3) RING DISPLAY AVAILABLE RINGS
4) AZF DISPLAY ALARM ZONES
5)
DOUT DISPLAY DIGITAL OUTPUTS
6) DIN DISPLAY DIGITAL INPUTS
7) HISTORY DISPLAY SYSTEM HISTORY
LIST MENU 2
01 OCT 1999 14:44:37
DOWNUP
MENU
USE BUTTONS/NUMBERS TO SELECT A FUNCTION
A = 0
F = 0
I = 0
N = 0
SELECT
Menu Item Explanation
ALARM
Displays all current alarms on the system in chronological order and allows you to
acknowledge reset and isolate alarmed points using the soft buttons.
FAULT
Displays all current faults on the system in chronological order, and allows you to
acknowledge, reset and isolate fault points using the soft buttons
ISOLATED
Displays all currently isolated points on the system and provides a soft button for de-isolation.
ACTIVE
Displays all active Non-Alarm (supervisory) events on the system in chronological order
and allows you to acknowledge, reset and isolate points using the soft buttons.
LIST
Moves you to List Menu 2 with the menu items listed below
ZONE
Display zones as per AS4428. Allows editing of displayed zone names for Fire-
fighters display purposes.
FLASHSCAN
Displays FlashScan
loops 1-10 and detectors/modules with names for status
viewing, editing and testing.
RING
Displays the systems communications rings and modules found on each.
AZF
Displays all system AZF’s and shows current status. Soft Buttons provide ability to
Test and Change a points programming.
DOUT
Displays all system Digital Outputs (Relays) and shows current status. Soft
Buttons provide ability to Test and Change a points programming.
DIN
Displays all system Digital Inputs and shows current status. Soft Buttons provide
ability to Test and Change a points programming.
HISTORY
Displays the systems history event buffer in chronological order.
