AFP-2800 - Fire Indicator Panel – Panel Operation Page 35
©
N
OTIFIER
I
NERTIA
P
TY
L
TD
,
2001
WWW
.
INERTIA
.
COM
.
AU
4.3.3.8
4.3.3.84.3.3.8
4.3.3.8 S
SS
S
ERVICE
ERVICE ERVICE
ERVICE
M
MM
M
ENU
ENU ENU
ENU
- L
- L- L
- L
IST
IST IST
IST
- AZF
- AZF- AZF
- AZF
This screen will display all conventional alarm zones (AZF’s) detected on the system. Zones which have been
allocated zone numbers will display the zone number, the physical point number (Ring/Module/I/O format), and the
zone description.
Unallocated zones will default to Z??? for the zone number, and the description will be the type of field module to
which the zone belongs. i.e. (AZM8 etc.)
Z 1 00.001.Z01 PANEL BREAK GLASS
Z 2 00.001.Z01 PANEL DOOR OPEN x
Z 3 01.001.Z01 CARPARK L4
Z 4 01.001.Z02 CARPARK L3
Z 5 01.001.Z03 CARPARK L2
Z 6 01.001.Z04 CARPARK L1 I
Z 7 01.001.Z05 LOBBY
Z ??? 01.001.Z06 (AZM8)
Z ??? 01.001.Z07 (AZM8)
Z ??? 01.001.Z08 (AZM8)
Z 20 01.002.Z01 LEVEL 1 CORRIDOR
Z 21 01.002.Z02 LEVEL 2 CORRIDOR
Z 44 01.002.Z03 ROOM 212
Z 45 01.002.Z04 ROOM 213
Z 46 01.002.Z05 ROOM 214
Z 99 01.002.Z06 LIFT MOTOR ROOM F
Z ??? 01.002.Z07 (PAZM8)
Z ??? 01.002.Z08 (PAZM8)
ALARM ZONE LIST
01 OCT 1999 14:44:37
CHANGETESTDOWNUP BACK
USE UP/DOWN BUTTONS TO SELECT A ZONE:
A = 0
F = 1
I = 1
N = 1
Actions:
• Use the UP
and DOWN buttons to scroll through
AZF points.
• When highlighting an AZF input point, Pressing the
TEST
button will take you into the test menu for
AZF’s (refer page 51). Which provide the options for
an Alarm and Fault test.
• Pressing the CHANGE
button will take you to the
Modify Point Screen (refer to page 42)
• Pressing the BACK
button return you back to the
Service Menu
In the above example, the following abbreviations of STATUS apply.
Status
Abbreviation
Meaning
AAlarm
IIsolated
FFault
X Activated
Note: You can also use the arrow keys, the Page Up and Page Dn keys on an external keyboard for scrolling functions.
