Page 54 AFP-2800 - Fire Indicator Panel – Panel Operation
© N
OTIFIER
I
NERTIA
P
TY
L
TD
, 2001
WWW
.
INERTIA
.
COM
.
AU
4.3.8.1
4.3.8.14.3.8.1
4.3.8.1 S
SS
S
ERVICE
ERVICE ERVICE
ERVICE
M
MM
M
ENU
ENU ENU
ENU
– G
– G– G
– G
LOBAL
LOBAL LOBAL
LOBAL
- S
- S- S
- S
YSTEM
YSTEMYSTEM
YSTEM
This page displays system global parameters that can be toggled. The default states are shown below on the left,
while the toggled states are shown on the right.
Default Condition Toggled Condition
FAULTS ARE NOT LATCHED
SHORTS ARE DEFINED AS ALARMS
FF SCREEN ALARMS ARE SHOWN AS GROUP ZONES
ALARM/FAULT TESTS ARE AUTO CLEARED
FAULT LIST MANUAL SWITCHED
ACTIVE LIST MANUAL SWITCHED
EVENT PRINTING IS OFF
ALARM ONLY EVENT PRINTING IS OFF
DISPLAY IS BLACK ON WHITE
SYSTEM CONFIGURATION
TOGGLEDOWNUP MENU
SELECT A FUNCTION:
01 OCT 1999 14:44:37
A = 0
F = 0
I = 0
N = 1
FAULTS ARE LATCHED
SHORTS ARE DEFINED AS FAULTS
FF SCREEN ALARMS ARE SHOWN AS SINGLE POINTS
ALARM/FAULT TESTS ARE MANUAL CLEARED
FAULT LIST AUTO SWITCHED
ACTIVE LIST AUTO SWITCHED
EVENT PRINTING IS ON
ALARM ONLY EVENT PRINTING IS ON
DISPLAY IS WHITE ON BLACK
SYSTEM CONFIGURATION
TOGGLEDOWNUP MENU
SELECT A FUNCTION:
01 OCT 1999 14:44:37
A = 0
F = 0
I = 0
N = 1
Actions:
• Use the UP
and DOWN buttons to scroll through options and then use the TOGGLE button to select the
toggle the highlighted option . Changes are instant.
• Press the MENU
button to return to the Service Menu screen.
Explanation of Global Configuration Options.
Item Description
Faults Latched / Non Latched
Determines if faults will self clear or remain latched until a manual reset.
Shorts defined as faults or
alarms
For some markets a short circuit on an AZF is to be classified as a fault. Please
note this would require all Break Glass units and other hard contact devices to
be fitted with a resistor.
FF Screen shows individual
Alarms or group zones
AS4428.1 has a requirement for Addressable points to show the zone to which
they belong in the FF screen and not all the individual alarms. Please note that
when in this mode only the zone in alarm is displayed, if you want to know which
points are in alarm you must go to the service menu and view alarms. A reset or
isolate in the group zones FF screen will isolate / reset all points in the zone.
Alarm/Fault Test Auto clear or
manual clear
During an AZF test you can control whether a point will automatically clear itself
once the test is successfully completed or remain latched until a manual reset.
Fault List Manual Switched or
auto switched
This setting determines if the panel should automatically jump to the fault list if a
fault event comes in and there are no alarms on the system.
Active List Manual Switched
or auto switched
This setting determines if the panel should automatically jump to the active list if
a Non-alarm event comes in and there are no alarms on the system.
Event Printing Enabled /
Disabled
This setting determines if the panel should print events to the printer port.
Alarm Only Printing activated
/ de-activated
This setting determines if the panel should only print alarm events or all events.
