The following screens are used for printing hard copies of information to a serial printer connected to CONN1 on
the back of the CPU board.
• Please refer to global settings menu on page 54 for enabling / disabling event printing options.
• Please refer to page 75 for information on printer port settings and cable requirements.
1)
ALARM LIST PRINT CURRENT ALARM LIST
2)
FAULT LIST PRINT CURRENT FAULT LIST
3)
ISOLATE LIST PRINT CURRENT ISOLATE LIST
4)
ACTIVE LIST PRINT CURRENT ACTIVE LIST
5)
HISTORY PRINT HISTORY
6)
SCRIPTS PRINT CONTROL SCRIPTS
7)
FLASHSCAN PRINT FLASHSCAN DEVICES
8)
RING MODULES PRINT MODULES ON RING 1&2
PRINT MENU
SELECTDOWNUP MENU
USE UP/DOWN BUTTONS TO SELECT A FUNCTION
01 OCT 1999 14:44:37
A = 0
F = 0
I = 0
N = 1
Actions:
• Use the UP
and DOWN buttons to scroll
through options and then use the SELECT
button
to select the highlighted option
(or button 1
to 8 from the numeric keypad)
• Press the MENU
button to return to the Service
Menu screen.
Selection Result
Alarm List
Prints all Alarm events currently on the system.
Fault List
Prints all points currently in fault on the system.
Isolate List
Prints all Isolated points on the system.
Active List
Prints all Non-Alarm points which are currently active on the system.
History
Prints system history with the following options for printing:
• All Alarm in Ascending Date Order.
• All Faults in Ascending Date Order.
• All Isolates in Ascending Date Order.
• All Active events in Ascending Date Order.
• All history events starting from a selected date.
Scripts
Prints all outputs points which are operated by scripts.
FlashScan

Prints all installed FlashScan

points.
Ring Modules
Prints all installed modules on rings 1 & 2.
