General Information The Main Menu
CO-OP: D100,158 - Indicates the address(es) of any detector(s) linked with the detector
that’s in alarm for Co-operative Multi-alarm Sensing. This field does not display for
Acclimate, FSC-851 IntelliQuad, FCO-851 detectors, Beam detectors or Heat detectors.
CO: - FSC-851 IntelliQuad and FCO-851 detectors only, FlashScan only - Carbon Monoxide
reading in parts per million.
TEMP: -Displays degrees Centigrade for Acclimate, FSC-851, FCO-851, heat, and
aspiration detectors
Line 15 - The current time and date are displayed in this line.
Line 16
BACK - Press to return to the previous screen.
1.7.3 History Display (History Select Screen)
The History Select screen allows the user to select a type of history file to view, and to set time/date
or point range viewing parameters. The particular menu items will not appear on the History
Display screen if no associated events are in the queue.
Figure 1.10 History Display Select Screen
Soft Keys
ALL EVENTS, ALARMS ONLY, FAULTS ONLY, SUPERVISORY ONLY, AND OTHERS
- Pushing the associated soft key selects the type of history to be viewed.
TIME/DATE INTERVAL - Sets a time/date interval of events to be displayed.
POINT RANGE - Sets a range of points for which events will be displayed.
Refer to the section Section 4, “Viewing and Printing History Information”, on page 52 for a full
description of History Select.
1.7.4 Read Status
Pressing the Read Status soft key brings up screens to view the present status of points, zones, and
other system information. Refer to the section Section 3, “Read Status”, on page 40 for a full
description of Read Status.
1.7.5 Program/Alter Status
Pressing the Program/Alter Status soft key brings up screens for panel programming, point
programming, autoprogramming, clear programming, altering the status of points, walk test, and
other information. A password is required. Refer to this panel’s programming manual for
information on these functions.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
11:58:43A TUE DEC 23, 2014 N124
HISTORY SELECT
ALL EVENTS OTHERS
ALARMS ONLY TIME/DATE INTERVAL
FAULTS ONLY POINT RANGE
SUPERVISORY ONLY BACK
