AFP-3030 Operations Manual — P/N DOC-01-039:A 26/11/2015 52
Section 4: Viewing and Printing History Information
The control panel maintains a history file of alarm, fault, and supervisory events, each with a
time/date stamp. An alarm history is maintained in a buffer that can include up to 1000 events. All
events, including alarms, are included in a 4000-event buffer. History events may be viewed on-
screen, and a printed list may be generated.
To choose a history display screen:
Press the HISTORY DISPLAY soft key at the Main Menu. The following menu screen titled His-
tory Display will appear.
Press the soft key for the type of event history desired to view all of those types of events that
are in the history buffer,
OR
Press the TIME/DATE INTERVAL or POINT RANGE soft key to choose limiting parameters
for what will display on-screen.
The following sections illustrate and explain the history displays.
4.1 Events History
Pressing a soft key on the History Select screen will display the history for whatever event type
chosen. The OTHER softkey will display disable, prealarm, active, and active outputs events. If the
ALL EVENTS soft key is pressed, any events in the history file will display, no matter what the
type.
The screen below is an example of what displays when the ALL EVENTS soft key is pressed. The
displayed fields are the same for each event type.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
11:58:45A TUE JAN 25, 2011 N124
HISTORY DISPLAY
ALL EVENTS OTHERS
ALARMS ONLY TIME/DATE INTERVAL
FAULTS ONLY POINT RANGE
SUPERVISORY ONLY BACK
To Next Page
