Viewing and Printing History Information Time and Date Range Selection for All Events
Figure 4.1 Event History Screen
Display
Lines 1-4: Displays any current event message, or, as in this example, the System Normal message
Line 5: Screen title. It will vary depending on the history type chosen for viewing. For example, it
will display
ALARM HISTORY if the ALARMS ONLY soft key is pressed at the History Select
screen.
Line 6: Queue location of event that is described in lines 8-11: In the above example, the fire alarm
is the fourth of 17 events in the history file.
Lines 8 through 11 give more information about the event. Refer to Section 1.5.2, “Event Reporting
Format”, on page 6 for an explanation of these fields.
Soft Keys
NEXT EVENT - Press to view next event (In the above example, event 005 of 017).
PREVIOUS EVENT - Press to view previous event (In the above example, event 003 of 017).
PRINT “xxx” HISTORY - Press to print the history for the event(s) chosen. (In the above exam-
ple, all 17 events). The report will look like this:
4.2 Time and Date Range Selection for All Events
Pressing the Time/Date Interval soft key on the History Select screen displays the Time & Date
Range Select screen. This screen allows for selection of a time period that defines the range of
events to be viewed and/or printed.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
11:58:45A TUE JAN 25, 2011
EVENT HISTORY
EVENT 004 OF 017
FIRE ALARM MAGNET
ELEVATOR LOBBY EAST WING
FIFTH FLOOR Z005 SMOKE ACCLIM
10:43:45A TUE JAN 25, 2011 L03D157
NEXT EVENT PRINT EVENT HISTORY
PREVIOUS EVENT BACK
MAGNET indicates that the device event occurred due to a magnet activation.
NOTE: If an Acclimate™ Detector activates, the event history screen will display whether it was
due to heat or smoke. This will be shown in Line 8 and will also show in a printed history report.
******EVENT HISTORY*************************************************************
FAULT
TM4 NO ANSWER 08:52:05P SAT MAR 5, 2011
ACK FAULT
TM4 NO ANSWER 08:53:35P SAT MAR 5, 2011
CLEAR FAULT
TM4 NO ANSWER 08:54:05P SAT MAR 5, 2011
********************************************************************************
