49 AFP-3030 Operations Manual — P/N DOC-01-039:A 26/11/2015
Read Status Fault Zone
3.11 Fault Zone
When a Fault zone address is entered into the Point Select Screen and the ACCEPT soft key is
pressed, the following screen will display:
Figure 3.12 Fault Zone Screen - Read Status
Display
Lines 1 through 6 - Refer to the descriptions in Section 3.2, “Smoke Detector”, on page 41.
EQUATION: The equation for this Fault zone is displayed here.
Line 15 - Current time and date.
3.12 Annunciator
When an annunciator address is entered into the Point Select Screen and the ACCEPT soft key is
pressed, the following screen will display if the point is a monitor module.
Figure 3.13 Annunciator Screen - Read Status
Display
Lines 1- 4 - This could display any current event message, or, as in this example, the System Nor-
mal message
Line 5 - Screen title and the address of the point being read.
Line 6 - Displays the annunciator mode.
Line 7 - Displays the state of the active LED.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A TUE JAN 25, 2011
READ ADDRESS: N124ZT008
AUTOMATIC INACTIVE
FAULT ZONE NUMBER 008 ZT008
EQUATION:
AND(T15,T16)
10:22:34A TUE JAN 25, 2011
BACK
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A TUE JAN 25, 2011
READ ADDRESS: N124A08P09
MODE: CONTROL
ACTIVE LED: OFF
FAULT LED: OFF
SOURCE: L01M001 L01M002
BACK
