63 AFP-3030 Operations Manual — P/N DOC-01-039:A 26/11/2015
Appendix A: Software Type ID Codes
A.1 Alphabetical List
The following chart lists AFP-3030 Type ID codes in alphabetical order. These codes are assigned
during programming based on the types and functions of the devices they are assigned. The codes
appear in point message formats.
Software Type ID Code Device
ABORT SWITCH Monitor that provides an abort function for a releasing zone through connection to an abort
station
ACK SWITCH Monitor used to silence panel sounder, and to give an acknowledge message on the panel
display
ACCL (P Sup) Acclimate detector with photo activating supervisory event
ACCL+ (P Sup) Acclimate plus detector with photo activating supervisory event
AIR REF FSL-751 detector used to monitor air quality entering a protected area
ALARM DEV Supervised NAC for speaker circuits.
ALARM DEV FLT Monitoring audio equipment.
ALARMS PEND Control module or NAC for output that will activate upon receipt of an alarm condition, and
remain in the alarm state until all alarms have been acknowledged. Programmed for switch
inhibit
ALARM TRACK Supervise protected premises for all notification and evacuation.
ASPIR. (NON) For use with an aspiration detector, reports to the fire panel as a non-fire event when its
threshold is reached
ASPIR. (PRE) For use with an aspiration detector, reports to the fire panel as a prealarm condition when its
threshold is reached
ASPIR. (REF) For use with an aspiration detector, reports to the fire panel as a non-fire activation, used as a
reference for other aspiration detectors on the loop
ASPIR. (SUP) For use with an aspiration detector, reports to the fire panel as a supervisory when its threshold
is reached
ASPIRATION For use with an aspiration detector, reports to the fire panel as a fire alarm when threshold is
reached
AUXILIARY Control output which is used with the Auxiliary Disable button
BELL CIRCUIT Control module used with NAC with bells
blank Operates as CONTROL with no Type ID label
CO MONITOR Monitor Module for use with conventional CO detectors. Activation will generate a CO Alarm on
the FACP.
CONTROL Control module used with NAC
CONTROL NAC Control module or NAC
DBA Monitor for a Direct Brigade Access panel
DOOR HOLDER Control output which is used with the Door Holder Disable button
ECS/MN MON Monitor for mass notification alarms, latching
ECS/MN SUPL Monitor for mass notification supervisory inputs, latching
ECS/MN SUPT Monitor for mass notification supervisory inputs, tracking
ECS/MN TMON Monitor used for mass notification fault inputs, tracking
FIRE CONTROL Monitors non-fire activations
FMM-420 Monitors 4-20 mA industrial sensors
FORM C RESET Control module used to interrupt 24 V power to four-wire conventional detectors for 30 seconds
upon reset. Used in conjunction with a monitor module with a conventional detector Type ID
GEN ALARM Control module, XPC-8 circuit, or XP5-C (NAC mode) configured as a Municipal Box
Transmitter (MBT-1 required). This Type ID can also be used for general alarm activation. It is
programmed as “switch inhibit”.
GEN PEND Control module, XPC-8 circuit, or XP5-C (NAC mode) that will activate upon receipt of an alarm
and/or fault condition, and remain in the ON state until all events have been acknowledged
GEN SUPERVIS Control module, XPC-8, or XP5-C (NAC mode) activated under any supervisory condition
(includes sprinkler type). It is programmed as “switch inhibit”
Table A.1 Software Type ID Codes, Alphabetical List (1 of 3)
