AFP-3030 Operations Manual — P/N DOC-01-039:A 26/11/2015 50
DAA Speaker Circuit Read Status
Line 8 - Displays the state of the fault LED.
Line 10 - Displays the annunciator source(s).
3.13 DAA Speaker Circuit
When a DAA Speaker circuit address is entered into the Point Select Screen and the ACCEPT soft
key is pressed, the following screen will display.
Figure 3.14 Speaker Point - Read Status
Lines 1- 4 - This could display any current event message, or, as in this example, the System Nor-
mal message
Line 5 - Screen title and the address of the point being read.
Line 6 - Refer to the line 6 description in “Control Module” on page 46 for explanations of the mes-
sages that can appear in this line.
3.14 PAM Points
When a PAM (Prioritized Audio Matrix) address is entered into the Point Select Screen and the
ACCEPT soft key is pressed, the following screen will display.
Figure 3.15 PAM (Prioritized Audio Matrix) Point - Read Status
Lines 1 - 6 - Refer to the line 6 description in “Smoke Detector” on page 41
Line 9 - DVC General Zone Map.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A TUE JAN 25, 2011
READ ADDRESS: N012A23S2
AUTOMATIC OFF
10:22:34A TUE JAN 25, 2011
BACK
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A TUE JAN 25, 2011
READ ADDRESS: N012I0234A28SA
AUTOMATIC INACTIVE
Z103, Z035, Z199, Z200
MAPPED LOGIC EQUATION: NONE
WALK TEST: NO
SWITCH INHIBIT: YES
SILENCEABLE: YES
10:22:34A TUE JAN 25, 2011
BACK
