Preparing for Installation Section 3 Installation
NFS-3030 Installation PN 51330:C 10/28/2003 17
Section 3 Installation
3.1 Preparing for Installation
Choose a location for the fire alarm system that is clean, dry, and vibration-free with moderate
temperature. The area should be readily accessible with sufficient room to easily install and maintain it.
There should be sufficient space for cabinet door(s) to open completely.
Carefully unpack the system and inspect for shipping damage. Count the number of conductors needed
for all devices and find the appropriate knockouts. (Refer to Section 3.16 “UL Power-limited Wiring
Requirements” for selection guidelines.)
Before installing the fire alarm system, read the following:
• Review the installation precautions at the front of this manual.
• Installers should be familiar with the standards and codes specified in Section 1.1 “Standards
and Other Documents”.
• All wiring must comply with the National and Local codes for fire alarm systems.
• Do not draw wiring into the bottom 9 inches (22.86 cm) of the cabinet except when using a
separate battery cabinet; this space is for internal battery installation.
• Review installation instructions in Section 3.2 “Installation Checklist”.
3.2 Installation Checklist
The checklist that follows contains references to information included in other manuals; see Section 1.2
“Supplemental Documentation” for document part numbers.
!
WARNING: Make sure to install system components in the sequence listed below. Failure to do so
can damage the control panel and other system components.
!
WARNING: Wear a static discharge strap on wrist to prevent equipment damage.
Table 2 Installation Checklist (Sheet 1 of 2)
Task Refer to:
1. Mount the cabinet backbox to the wall. Section 3.3 “Mounting a Cabinet”
2. Attach CPU to chassis Section 3.5 “Attaching the CPU & Chassis”
3. Attach panel circuit modules and
option boards (e.g. SLC loop modules,
network control modules, and other
devices of the same size) to chassis.
• Section 3.6 “Attaching Option Boards”
• Section 3.7 “Attaching Panel Circuit Modules”
• Section 3.14 “Connecting Specific Option Boards”
• Installation document for the specific device
4. Attach chassis to backbox as
appropriate for system design
Section 3.4 “Laying Out Equipment in Cabinet and Chassis”
5. Wire Notification Appliance Circuits,
Initiating Device Circuits, and Relays
• Section 3.8 “Initiating Device Circuits with IZM-8RK/IZE-A”
• Section 3.9 “NACs with ICM-4RK⁄ICE-4”
• Section 3.10 “Form-C Relays on the CPU”
• Section 3.11 “Form-C Relays with CRM-4RK/CRE-4”
• Section 3.12 “Form-C Relays with Auxiliary Relay Module (ARM-4)”
6. Attach & wire other system components
Voice Alarm System components Voice Alarm System Manual
Annunciators and other ACS
devices
ACS Manual, LCD-80 Manual, etc.
Remote Data Port devices LCD-160 Manual
To Next Page
