Section 3 Installation Installing Printers
44 NFS-3030 Installation PN 51330:C 10/28/2003
3.18.2 Configuring the Printer
Refer to the documentation supplied with your printer for instructions on configuring your printer.
PRN-5 Printer Settings
Set the printer options (under the menu area)
according to the settings listed in Table 5.
Keltron Printer VS4095/5 Settings
The printer communicates using the following
protocol:
•Baud Rate
Supervised mode: 2400
Unsupervised mode: 300
(Supervision is a programmed setting;
refer to the Panel Programming section of
the Programming Manual for
instructions.)
• Data bits: 8
•Parity: None
• Stop bits: 1
Set the printer DIP switches SP1 and SP2
according to settings in Table 6 below:
Table 6 Keltron DIP Switch Settings
Table 5 PRN-5 Setup Options
Option Setting
L/R Adjust
Font
CPI
LPI
Skip
ESC Character
Emulate
Bidirectional Copy
I/O
Interface
Buffer
Serial
Baud
Format
Protocol*
CG-TAB
Character Set
Country
Select Zero
Auto-CR
Auto-LF
Menu Lock
Language
Paper
Single
Form Adjust
Trac 1
Form Adjust
Trac 2
Form Adjust
Auto Sheet Feeder
Form Adjust
Auto Tear
F-Eject
Form Length
Trac 1
Lines
Standard
Trac 2
Lines
Standard
Barcode
Barmode
0
HS Draft
10 CPI
6 LPI
0.0
ESC
FX-850
ON
Serial
40K
9600
8 Bit, None, 1 Stop
ENQ/STX
Graphic
Standard
E-USA ASCII
ON
OFF
OFF
ON
English
12/72
12/72
12/72
12/72
OFF
OFF
66
10.5”
66
10.5”
Off
Unsecured
Note: When printing in graphics mode,
set I/O Serial Protocol to “Robust XON/OFF”.
Supervised Unsupervised
SP1 On Off SP1 On Off
1X1X
2X 2 X
3X3X
4X4X
5X 5X
6X6X
7X 7X
8X 8X
Supervised and
Unsupervised
SP2 On Off
1X
2X
3X
4X
5X
6X
7X
8X
To Next Page
