Section 3 Installation Form-C Relays on the CPU
34 NFS-3030 Installation PN 51330:C 10/28/2003
Field Wiring an Auxiliary Relay Module
The figure above shows terminal assignments for ARM-4 module control relays K1-K4, which control
non-power-limited circuits. Power-limited and non-power-limited circuit wiring must remain separated
by at least 0.25 inch (6.35 mm) within the cabinet and exit the cabinet though different knockouts,
conduits, or both. Refer to Section 3.16 “UL Power-limited Wiring Requirements”.
The table contains contact ratings for relays K1-K4 on the ARM-4 module:
Table 3 Contact Ratings for K1-K4 on the ARM-4 Module
Resistive Load
Contacts
Normally Open (N.O.) Normally Closed (N.C.)
125 VAC 20 A 10 A
30 VDC 20 A 10 A
