5. Maintenance Menu
5.3.1.11 Self-diagnostic function setting
This self-diagnostic menu is used to set valid/invalid of the error detection by the various
sensors.
The error detection can be made invalid or valid for locating source of abnormality.
However, this menu item requires expert knowledge to set among the engine operations.
Handle this menu item with utmost care.
Be sure to return the setting to the default setting upon completion of usage of this item.
1. E
nt
er the self-diagnostic mode (level 1) and keep pressing the [MENU+] or
[MENU-] key until the following message is displayed.
SENSOR SETTING
2. When the [ENTER] key is pressed, the following message is displayed. Keep
pressing the [MENU+] or [MENU-] key until the target item (refer to the table
below) is displayed.
TONER SENSOR
ENABLE *
3. When the [ENTER] key is pressed, the following message is displayed.
Pressing the [MENU+] key increments the setting value.
Pressing the [MENU-] key decrements the setting value.
4. While the desired setting value is being displayed, press the [ENTER] key for
long period (3 seconds) that registers the displayed value in EEPROM. (Returns
to the status of step 2.)
5. Repeat steps 2 to 4 as required.
6. P
re
ssing the [BACK] key terminates (except the status of step 4) the setting.
(Returns to the status of step 1.)
Display Setting value
Operation at the
setting value
Function
TONER
SENSOR
ENABLE Detects Valid/Invalid of toner sensor
operation
DISABLE Not to detect
BELT UNIT
CHECK
ENABLE Chec
ks Valid/Invalid of belt installation check
operation
DISABLE Not to check
Display Setting value
Operation at the
setting value
Function
ID UNIT
CHECK
ENABLE Checks Valid/Invalid of ID installation check
operation
DISABLE Not to check
UP/DOWN
SENSOR
ENABLE Detects Valid/In
valid of ID UP/DOWN sensor
operation
DISABLE Not to detect
REG ADJUST
ERROR
ENABLE Stops Valid/Invalid of error stop by the
color registration detection value
DISABLE Not to stop
DRUM OVER
LIFE
STOP Not to continue Setting of valid/invalid of continuance
when drum comes to end of its life
CONTINUANCE To continue
WR POINT
REV
TBL=**H±
*.***mm
00H~FFH Correction value The correction value is added to the
existing write-down position.
BOTTOM
WRT POINT
TBL=**H±
*.***mm
00H~FFH Cut value Amount of cut at the rear end of a
paper is set.
Hatched portion: Default is shown
