Oki C711 User Manual

44205401TH Rev.1
113 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
5.3.1.12 LED head serial number display
This self-diagnostic menu item is used to check whether the downloaded LED head data
matches the serial number of the actual LED head.
1. Ent
er the self-diagnostic mode (level 1) and press the MENU+, MENU- key
until "SWITCH SCAN" is displayed in the upper row of the display area.
(Pressing the MENU+ key increments the test item and pressing the MENU- key
decrements the test item.)
2. When the MENU+
key or the MENU- key is pressed, serial numbers of the K/Y/
M/C LED head data are displayed in order.
3. Pressing the BACK ke
y terminates the test. (Returns to the status of step 1.)
K ** ** ** ****
xxxxxxxxxxxxx
** ** ** ****: Rev number
Xxxxxxxxxxxxxxxx: serial number
5.3.1.13 NVRAM parameter setting
Do not use this menu item.
5.3.2 Various prints with the printer as a standalone unit
Menu map print
Information of the program version number and that of the control block configuration are
printed out.
Operation:
While the system is in the [Ready To Print] state, press the ENTER key once to
display [Print Information].
Press the ENTER key to display [Configuration/Execute].
Press the ENTER key.
Network information print
Operation:
While the system is in the [Ready To Print] state, press the ENTER key once to
display [Print Information].
Press the ENTER key.
Press the MENU+ key several times to display [Network/Execute].
Press the ENTER key.
Demo print
Prints the demo patterns of the various destinations that are saved in the ROM.
Operation:
While the system is in the [Ready To Print] state, press the ENTER key once to
display [Print Information].
Press the ENTER key.
Press the MENU+ key several times to display [Demo Page/Execute].
Press the ENTER key.
