Chapter 9: Vertical Control Commands 87
Form Feed Command (IBM/E/ML)
⻬ ML320 E/I, ML321 E/I ⻬ ML320 Turbo, ML321 Turbo ⻬ ML520, ML521
⻬ ML320 Std., ML321 Std. ⻬ ML390 Turbo, ML391 Turbo ⻬ ML590, ML591
Function ASCII Dec Hex
Form Feed FF 12 0C
When you send a form feed command, the printer prints any data that is in its buffer, and the
print position moves to the top of the next page. You can also use the FORM FEED button on
the control panel to feed a page through the printer.
Line Feed Commands
Line Feed with Carriage Return Command (IBM/E/ML)
⻬ ML320 E/I, ML321 E/I ⻬ ML320 Turbo, ML321 Turbo ⻬ ML520, ML521
⻬ ML320 Std., ML321 Std. ⻬ ML390 Turbo, ML391 Turbo ⻬ ML590, ML591
Function ASCII Dec Hex
Line Feed, with Carriage Return LF 10 0A
This command makes the printer print a line, then moves the print position down one line and
executes a carriage return, putting the print position at the left margin. The amount of vertical
movement depends on the current line spacing. (See “Line Spacing,” below for details.)
In the IBM and Epson emulations, this command cancels one-line double width printing.
Line Feed without Carriage Return Command (ML)
⻬ ML320 Std., ML321 Std. ⻬ ML320 Turbo, ML321 Turbo ⻬ ML520, ML521
Function ASCII DEC Hex
Graphics Line Feed, without Carriage Return ESC DC2 27 18 1B 12
This command drops the printing down a line without returning to the left margin. This makes
it possible to overstrike a line of printing or create special effects such as double underlines.
Line Feed & Carriage Return Selection Command (ML)
⻬ ML320 Std., ML321 Std. ⻬ ML320 Turbo, ML321 Turbo ⻬ ML520, ML521
Function ASCII Dec Hex
Select Line Feed & Carriage Return ESC ? n : 25 63 n 58 1B 3F n 3A
This command performs a number of different carriage return/line feed combinations,
depending on the value of n:
Table 60: ML ESC ? Command —
Carriage Return/Line Feed Codes for n Values
Value of n Operation
To Next Page
