IBM Mode 37
English
and 12 CPI, and half the height of standard characters at 15 CPI, 17.1 CPI
or 20 CPI.
Underlining
With this feature an unbroken line is printed under characters and the
spaces between characters.
Note:
The underline feature prints a line which overlaps
the end of the tails on descending characters (that is
p, g, etc.). This feature will not operate in the High
Speed Draft (HSD) mode.
Over Scoring
The over score command causes a line to be drawn above the designated
characters. Spaces specified by the horizontal tab command will not be
over scored.
FORMATTING FEATURES
Page Length Top of Form & Form Feed
After setting page length, the printer knows what size paper is being used.
When the printer is switched on, the current location of the print head is
recorded as the top of form, which is the position of the first line of printing
on the page below the top margin. Inserting a Form Feed command after
printing several lines moves the paper to the first printing line of the next
page.
Superscripts & Subscripts Decimal Hex. ASCII Comp.
Start superscripts 27 83 48 1B 53 30 ESC S 0 P F
Start subscripts 27 83 49 1B 53 31 ESC S 1 P F
Stop super/subscripts 27 84 1B 54 ESC T P F
Underlining Decimal Hex. ASCII Comp.
Start continuous underlining 27 45 49 1B 2D 31 ESC - 1 P F
Stop underlining 27 45 48 1B 2D 30 ESC - 0 P F
Over Scoring Decimal Hex. ASCII Comp.
Start over scoring 27 95 49 1B 5F 31 ESC _ 1 P
Stop over scoring 27 95 48 1B 5F 30 ESC _ 0 P
