6
PC Setup Section 1-1
DM 6629 00 to 07 Number of TIMH(15) High-speed Timers to Refresh by Interrupt Refreshing
00 to 15 (BCD; e.g., set 3 for timers 00 to 02)
15
08 to 15 High-speed Timer Interrupt Refresh Enable
00: 16 timers (setting in bits 00 to 07 disabled)
01: Use setting in 00 to 07
DM 6630 00 to 07 First Input Refresh Word for I/O Interrupt 0: 00 to 11 (BCD) 26
08 to 15 Number of Input Refresh Words for I/O Interrupt 0: 00 to 12 (BCD)
DM 6631 00 to 07 First Input Refresh Word for I/O Interrupt 1: 00 to 11 (BCD)
08 to 15 Number of Input Refresh Words for I/O interrupt 1: 00 to 12 (BCD)
DM 6632 00 to 07 First Input Refresh Word for I/O Interrupt 2: 00 to 11 (BCD)
08 to 15 Number of Input Refresh Words for I/O Interrupt 2: 00 to 12 (BCD)
DM 6633 00 to 07 First Input Refresh Word for I/O Interrupt 3: 00 to 11 (BCD)
08 to 15 Number of Input Refresh Words for I/O Interrupt 3: 00 to 12 (BCD)
DM 6634 00 to 07 First Input Refresh Word for High-speed Counter 1: 00 to 11 (BCD) 26
08 to 15 Number of Input Refresh Words for High-speed Counter 1: 00 to 12 (BCD)
DM 6635 00 to 07 First Input Refresh Word for High-speed Counter 2: 00 to 11 (BCD) 26
08 to 15 Number of Input Refresh Words for High-speed Counter 2: 00 to 12 (BCD)
DM 6636 00 to 07 First Input Refresh Word for Interval Timer 0: 00 to 15 (BCD) 32, 39
08 to 15 Number of Input Refresh Words for Interval Timer 0: 00 to 16 (BCD)
DM 6637 00 to 07 First Input Refresh Word for Interval Timer 1: 00 to 15 (BCD)
08 to 15 Number of Input Refresh Words for Interval Timer 1: 00 to 16 (BCD)
DM 6638 00 to 07 First Input Refresh Word for Interval Timer 2 or High-speed Counter 0:
00 to 15 (BCD)
08 to 15 Number of Input Refresh Words for Interval Timer 2 or High-speed Counter 0:
00 to 16 (BCD)
DM 6639 00 to 07 Output Refresh Method
00: Cyclic; 01: Direct
16, 475
08 to 15 Number of Digits for DIGITAL SWITCH (DSW(87)) Instruction
00: 4 digits; 01: 8 digits
16, 427
High-speed Counter Settings (DM 6640 to DM 6644)
The following settings are effective after transfer to the PC the next time operation is started.
DM 6640 to
DM 6641
00 to 15 Inner Board Slot 1 Settings (See 1-2 Inner Board Settings for details.) 9
DM 6642 00 to 03 High-speed Counter 0 Input Mode
0: Differential phase mode; 4: Incrementing mode
39
04 to 07 High-speed Counter 0 Reset Mode
0: Phase-Z and software reset; 1: Software reset only
08 to 15 High-speed Counter 0 Enable
00: Don’t use high-speed counter 0; 01: Use high-speed counter 0.
DM 6643 to
DM 6644
00 to 15 Inner Board Slot 2 Settings (See 1-2 Inner Board Settings for details.) 9
Word(s) Bit(s) Function Page
