Omron FS-C2KU7DGES-C User Manual

No.20S046-00
32/62
FS-C4KU7DGES-F / FS-C4KU7DGES-M42 / FS-C2KU7DGES-F / FS-C2KU7DGES-M42 / FS-C2KU7DGES-C
Product Specifications and Use’s Guide
10.2 Frame rate
This parameter sets the line rate (Hz) and frame rare (Hz) of output image from camera.
GenICam Parameters
AcquisitionLineRate IFloat Type Sets line rate in Hz unit (*1)
Range is changed with pixel format of image.
Default: 13,000.917712 (FS-C4KU7DGES-F, 8bits output /
FS-C4KU7DGES-M42, 8bits output)
26,001.835424 (FS-C2KU7DGES-F, 8bits output /
FS-C2KU7DGES-M42, 8bits output /
FS-C2KU7DGES-C, 8bits output)
AcquisitionFrameRate IFloat Type Sets frame rate in Hz unit (*1)
Range is changed with acquisition line rate, pixel format and height of
image.
Default: 26.001835 (FS-C4KU7DGES-F, 8bits output /
FS-C4KU7DGES-M42, 8bits output)
52.003671 (FS-C2KU7DGES-F, 8bits output /
FS-C2KU7DGES-M42, 8bits output /
FS-C2KU7DGES-C, 8bits output)
* The default frame is with default height (1,000 lines)
(*1) The approximate value of set value, sets to camera and display it.
10.3 Exposure Time
This parameter sets variable exposure time.
GenICam Parameters
ExposureMode IEnumeration Type Exposure control selection
Selection: “Off”, “Timed” and “TriggerWidth”
Off: Exposure time is “1 / Line rate”
Timed: Exposure time is “ExposureTime” for one line.
TriggerWidth: Exposure time is active pulse duration of input trigger signal
ExposureTime
[ExposureTime
Selector]
IFloat Type Exposure time (in μsecond) (*1)
Range: 2.000000 to
Default: 74.764706 (FS-C4KU7DGES-F / FS-C4KU7DGES-M42)
36.305882 (FS-C2KU7DGES-F / FS-C2KU7DGES-M42 /
FS-C2KU7DGES-C)
(*1) The longest exposure time will be change with AcquisitionLineRate and Pixel Format selection.

Omron FS-C2KU7DGES-C Specifications

General

Brand	Omron
Model	FS-C2KU7DGES-C
Category	Digital Camera
Language	English
