Omron FS-C2KU7DGES-C User Manual

No.20S046-00
42/62
FS-C4KU7DGES-F / FS-C4KU7DGES-M42 / FS-C2KU7DGES-F / FS-C2KU7DGES-M42 / FS-C2KU7DGES-C
Product Specifications and Use’s Guide
10.13 Encoder Control
The camera operation controls by Rotary Encoder.
GenICam Parameters
EcnoderSelector IEnumeration
Type
Selects Rotary Encoder.
Selection: Encoder0
Default: Encoder0
EncoderSourceA IEnumeration
Type
Selects input IO for A-phase of Rotary Encoder.
Selection: Off, Line0, Line1, Line2
Default: Off
EncoderSourceB IEnumeration
Type
Selects input IO for B-phase of Rotary Encoder
Selection: Off, Line0, Line1, Line2
Default: Off
EncoderMode IEnumeration
Type
Selects On / Off for jitter filtering for input encoder signal
Selection: FourPhase (with filtering), HighResolution (without filtering)
Default: FourPhase
EncoderDiviber IInteger Type Sets frequency division
Range: 1 to 65535
Default: 1
EncoderOutputMode IEnumeration
Type
Selects output signal condition that how does target object move
Selection: Off, PositionUP, PositionDown, DirectionUp,
DirectionDown, Motion
Default: Off
EncoderStatus IEnumeration
Type
Monitoring status of Rotary Encoder
EncoderTimeout IFloat Type The TimeOut event is occurring when no input signal from Rotary
Encoder for specified period of time.
EncoderResetSource IEnumeration
Type
Selects signal for reset Rotary Encoder
Selection: Off, AcquisitionStart, FrameStart, Line0, Line1, Line2,
SoftwareSignal0, SoftwareSignal1, LogicBlock0, Action0
Default: Off
EncoderResetActivation IEnumeration
Type
Selects signal condition for reset Rotary Encoder
Selection: RisingEdge, FallingEdge, AnyEdge, LevelHigh, LevelLow
Default: RisingEdge
EncoderReset ICommand
Type
Resets Rotary Encoder by software signal
EncoderValue IInteger
Type
Reads or sets current position counter for Rotary Encoder
EncoderValueAtReset IInteger
Type
Read the value of the position counter when reset Rotary Encoder
