9 - 13
9 Setting Up Slave Terminals
NX-series EtherNet/IP Coupler Unit User’s Manual (W536)
9-2 Setting Slave Terminal
Parameters
9
9-2-3 I/O Allocation Information
Registering I/O Entries
The I/O data assigned to an I/O entry mapping is called an I/O entry.
Default values are assigned to the I/O entries in each I/O entry mapping. Some I/O entry mappings
allow you to add or delete I/O entries. Also, the I/O data that you can assign to an I/O entry mapping
is predetermined. Change the I/O entries as necessary.
This section gives the I/O data in the EtherNet/IP Coupler Unit that you can assign as I/O for network
variables.
To access I/O data as NX objects, use the index numbers.
I/O Entry Mappings for EtherNet/IP Coupler Units
The following I/O entry mappings are available.
I/O Data Allocatable to I/O Entry Mappings
The following I/O data can be registered as I/O entries for the I/O entry mappings.
If you use a status that has a number as the suffix to the data name, select a status according to the
number of used NX Units. Doing so will reduce the I/O data size and improve communications per-
Allocatable I/O Data in an EtherNet/IP Coupler Unit
I/O I/O entry mapping name
I/O entry mapping I/O entry
Selecting Default Editing
Maximum
entries
Inputs 505th Transmit PDO Mapping Possible Selected Possible 5
I/O entry mapping D
I/O entry mapping A
I/O entry mapping B
I/O entry mapping C
Possible.Possible.
Editing
I/O entry
I/O entry mapping
Not possible.Not possible.
Not possible.Possible.
Possible.Possible.
I/O data A
I/O data B
I/O data J
I/O data C
I/O data D
I/O data E
I/O data F
I/O data G
I/O data L
I/O data H
I/O data I
I/O entries
I/O data K
I/O data M
Added.
Deleted.
Selected.
Selected.
Selected.
Allocatable I/O data points
I/O data not included
in the I/O entry
Not selected.
*The shaded I/O data is not exchanged with process data communications.
Selection of I/O
entry mapping
I/O entry
mapping
selection
example
To Next Page
