Model Conversion Instructions (Unit Ver. 3.0 or Later) Section 3-35
Description GETID(286) retrieves the data area address of the specified source variable
or address, outputs the data area code to D1 in 4-digit hexadecimal, and out-
puts the word address number to D2 in 4-digit hexadecimal.
The following table shows the variable type (data area) codes and corre-
sponding address ranges for the PLC’s data areas.
Variables in function blocks are automatically allocated addresses by CX-Pro-
grammer Ver. 5.0 and later systems, unless the AT specification is used. For
example, if it is necessary to indirectly specify the extended parameter set-
tings of a Special Unit such as a Motion Control Unit and a variable is used at
the beginning of the extended parameter settings area, that variable’s address
must be set. In this case, GETID(286) can be used to retrieve the variable’s
data area address.
Flags
Indirect DM/EM
addresses in binary
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
Indirect DM/EM
addresses in BCD
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
Constants ---
Data Registers DR0 to DR15
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
Area S D1 D2
Data area Data
size
Data area code
(Output to D1.)
Address
(Output to D2.)
CIO Area CIO Word 00B0 hex 0000 to 17FF hex
(0000 to 6143)
Work Area W 00B1 hex 0000 to 01FF hex
(000 to 511)
Holding Bit Area H 00B2 hex 0000 to 01FF hex
(000 to 511)
DM Area 0082 hex 0000 to 7FFF hex
(00000 to 32767)
EM Area
(Specific bank)
En_
(n = 0 to C)
00A0 to 00AC hex 0000 to 7FFF hex
(00000 to 32767)
Name Label Operation
Error Flag ER ON if S is not within the allowed range.
