Orolia Spectracom EC20S User Manual

EPSILON CLOCK MODEL EC20S Spectracom
User’s Manual 10
• Up to 10 x 10 MHz outputs
• 1 PPS and 10 MHz signals are phased locked, which helps prevent phase jump and wander between
time and frequency signals
• Remote monitoring via the Ethernet port thanks to built-in supervision interfaces (13 Web Interface,
14 SNMP Interface) - Stratum 1 time stamp over Ethernet 10/100 Base-T (RJ45 port).
• Local monitoring via signalling interfaces (11.1 Visual Signalling, 11.2, ALARMS Signalling).
2.2 DIMENSIONS AND WEIGHT
Width : 19" (441 mm), without bracket
Height : 1 U (44 mm).
Depth : 340 mm.
Weight : <4.7 kg.
Compatibility : 19” rack
The EC20S unit is compatible with 19” racks and can be mounted with slides. Screws to fix the slides on
the equipment sides are provides with the equipment. Use Slides Accuride, part number: DZ 2907-0020
Hub 559mm.

Orolia Spectracom EC20S Specifications

General

Brand	Orolia
Model	Spectracom EC20S
Category	Clock
Language	English
