the red test lead to the V/Ω/C terminal.
(3) Probe the test points and read the display.
Measuring Resistance
(1) Push DMM button on the front panel. Select in the bottom menu, select R.
(2) Connect the black test lead to the COM terminal on the back of the oscilloscope and
the red test lead to the V/Ω/C terminal.
(3) Probe the test points and read the display.
Testing Diodes
(1) Push DMM button on the front panel. Select in the bottom menu, select it until
switching to .
(2) Connect the black test lead to the COM terminal on the back of the oscilloscope and
the red test lead to the V/Ω/C terminal.
(3) Connect the red test lead to the positive terminal (anode) of the diode and the black
test lead to the negative terminal (cathode). The cathode of a diode is indicated with a
band. Read the diode forward bias.
Testing for Continuity
(1) Push DMM button on the front panel. Select in the bottom menu, select it until
switching to .
(2) Connect the black test lead to the COM terminal on the back of the oscilloscope and
the red test lead to the V/Ω/C terminal.
(3) Probe the test points to measure the resistance in the circuit. If the reading is below 50
, the multimeter will beep.
Measuring Capacitance
(1) Push DMM button on the front panel. Select in the bottom menu, select it until
switching to C.
(2) Insert the supplied capacitance measurer to the COM terminal and the V/Ω/C
terminal on the back of the oscilloscope.
(3) Insert the capacitance to the capacitance measurer, then screen shows the capacitance
reading.
Note: when measuring the capacitance which is less than 5 nF, please use relative value
measuring mode to improve measuring precision.
