Owon XDS3204E User Manual

11.Technical Specifications
146
Windows Time
30 ns to 10 s
For XDS3102AP/XDS3202A, the range is
8 bits mode
2 ns to 10 s
12 bits mode
4 ns to 10 s
14 bits mode
20 ns to 10 s
Timeout Trigger
Edge Type
Rising, Falling
Idle Time
30 ns to 10 s
For XDS3102AP/XDS3202A, the range is
8 bits mode
2 ns to 10 s
12 bits mode
4 ns to 10 s
14 bits mode
20 ns to 10 s
Nth Edge Trigger
Edge Type
Rising, Falling
Idle Time
30 ns to 10 s
Edge Number
1 to 128
Logic Trigger
Logic Mode
AND, OR, XNOR, XOR
Input Mode
H, L, X, Rising, Falling
Output Mode
Goes True, Goes False, Is True >,
Is True <, Is True =
RS232 Trigger
Polarity
Normal, Inverted
Trigger Condition
Start, Error, Check Error, Data
Baud Rate
Common, Custom
Data Bits
5 bit, 6 bit, 7 bit, 8 bit
I2C Trigger
Trigger Condition
Start, Restart, Stop, ACK Lost, Address,
Data, Addr/Data
Address Bits
7 bit, 8 bit, 10 bit
Address Range
0 to 127, 0 to 255, 0 to 1023
Byte Length
1 to 5
SPI Trigger
Trigger Condition
Timeout
Timeout Value
30 ns to 10 s
Data Bits
4 bit to 32 bit
Data Line Setting
H, L, X
CAN Trigger
(optional)
Signal Type
CAN_H, CAN_L, TX, RX
Trigger Condition
Start of Frame, Type of Frame, Identifier,
Data, ID & Data, End of Frame, Missing
Ack, Bit Stuffing Error
Baud Rate
Common, Custom
Sample Point
5% to 95%
Frame Type
Data, Remote, Error, Overload
Waveform Generator (Optional)
Performance
Characteristics
Instruction
Max Frequency Output
25 MHz
Sample rate
125 MSa/s
