The data type is signed integer. You can determine the data type (char, short int or int) based on
the BYTE parameter. The valid range is determined by the ADCB parameter, e.g. the valid range
for 8-bit ADC is -127 to +127.
How to Implement the Auxiliary System Function Setting
●Config
Push the Utility button, select Function in the bottom menu, select Configure in
the left menu.
The description of Configure Menu is shown as the follows:
●Display
Push the Utility button, select Function in the bottom menu, select Display in the
left menu.
The description of Display Menu is shown as the follows:
●Adjust
Lock all keys. Unlock method: push Trigger
Menu button in trigger control area, then push
Force button, repeat 3 times.
