Owon XDS3204E User Manual

11.Technical Specifications
148
General Technical Specifications
Display
Display Type
8" Colored LCD (Liquid Crystal Display)
Display Resolution
800 (Horizontal) × 600 (Vertical) Pixels
Display Colors
65536 colors, TFT screen
Output of the Probe Compensator
Output Voltage
(Typical )
About 5 V, with the Peak-to-Peak voltage ≥1 MΩ.
Frequency (Typical )
Square wave of 1 KHz
Power
Mains Voltage
100V - 240 VACRMS, 50/60 Hz, CAT Ⅱ
Power Consumption
XDS3062A
XDS3102(A)
＜15 W
XDS3102AP
XDS3112
XDS3202E
XDS3202(A)
XDS3302
＜24 W
Fuse
2 A, T class, 250 V
Battery (optional)
3.7V, 13200mAh
⚫ On XDS3062A, XDS3102(A), the battery can last
approximately 3.5 hours after charge fully.
⚫ On XDS3202(E), XDS3302, the battery can last
approximately 2.5 hours after charge fully.
Environment
Temperature
Working temperature: 0 ℃ - 40 ℃
Storage temperature: -20 ℃ - 60 ℃
Relative Humidity
≤ 90%
Height
Operating: 3,000 m
Non-operating: 15,000 m
Cooling Method
Fan cooling
Mechanical Specifications
Dimension
340 mm× 177 mm×90 mm (L*H*W)
Weight
Approx. 2.6 kg (without accessories)
Interval Period of Adjustment:
One year is recommended for the calibration interval period.

Owon XDS3204E Specifications

General

Brand	Owon
Model	XDS3204E
Category	Test Equipment
Language	English
