11.Technical Specifications
140
11. Technical Specifications
Unless otherwise specified, the technical specifications applied are for XDS3000
dual-channel series only, and Probes attenuation set as 10X. Only if the oscilloscope
fulfills the following two conditions at first, these specification standards can be
reached.
◼ This instrument should run for at least 30 minutes continuously under the
specified operating temperature.
◼ If change of the operating temperature is up to or exceeds 5℃, do a
"Self-calibration" procedure (see "How to Implement Self-calibration" on P14).
All specification standards can be fulfilled, except one(s) marked with the word
"Typical".
Oscilloscope
Performance Characteristics
Instruction
Bandwidth
XDS3062A
60 MHz
XDS3102(A)
XDS3112
100 MHz
XDS3102AP
8 bits mode
12 bits mode
100 MHz
14 bits mode
25 MHz
XDS3202E
200 MHz
XDS3202A
8 bits mode
200 MHz
12 bits mode
150 MHz
14 bits mode
20 MHz
XDS3202
200 MHz
XDS3302
300 MHz
Vertical Resolution (A/D)
XDS3062A
12 bits
XDS3102A
12 bits
XDS3102AP
14 bits
XDS3102
8 bits
XDS3202E
8 bits
XDS3202A
14 bits
XDS3112
XDS3202
8 bits
XDS3302
8 bits
Channel
2 + 1 (External)
Waveform Refresh Rate
75,000 wfms/s
Multi-level Gray Scale Display &
Color Temperature Display
XDS3062A
XDS3102A
Not support
