The wire which is coloured brown must be connected to
the terminal which is marked with the letter L or coloured
red.
NOTE
After replacing or changing a fuse, the fuse cover in the
plug must be replaced with a fuse cover which
corresponds to the colour of the insert in the base of the
plug or the word that is embossed on the base of the plug,
and the appliance must not be used without a fuse cover.
If lost replacement fuse covers can be obtained from your
dealer.
Only 13 A fuses approved by B.S.I or A.S.T.A to B.S.1362
should be used.
P3-4-2-1-2-1_En
The wires in this mains lead are coloured in
accordance with the following code:
Green and Yellow : Earth
Blue : Neutral
Brown : Live
If the plug provided is unsuitable for your socket outlets,
the plug must be cut off and a suitable plug fitted.
IMPORTANT
FOR USE IN THE UNITED
KINGDOM.
The cut-off plug should be disposed of and must not be
inserted into any 13 amp socket as this can result in
electric shock. The plug or adaptor or the distribution
panel should be provided with 13 A fuse. As the colours of
the wires in the mains lead of this appliance may not
correspond with coloured markings identifying the
terminals in your plug, proceed as follows ;
The wire which is coloured green and yellow must be
connected to the terminal in the plug which is marked
with the letter E or by the earth symbol , or coloured
green or green and yellow.
The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or coloured
black.
Replacement and mounting of an AC plug on the power supply cord of this unit should be performed only by qualified service
personnel.
