Pioneer PDP-4270XD User Manual

Setting up08
32
En
7 Press HOME MENU to exit the menu.
Note
• For the 3DYC, the individual parameters are selectable only when:
– You have selected INPUT 1, 2, or 3 as the input source and "Video"
as the input signal type (see page 45); or
– You have selected INPUT 4 as the input source and have not
connected a S-Video cable; or You have selected the analogue
tuner.
• The 3DYC setting is ineffective when SECAM, PAL60, or 4.43NTSC
signals are input.
• For the I-P Mode, the individual parameters are not selectable for
the following input signals: 480p, 720p@60 Hz, 576p, 720p@50 Hz,
1080p@24 Hz.
Sound adjustments
You can adjust the sound quality to your preference with the following
settings.
Adjust the sound to your preference for the chosen AV Selection
option. See AV Selection on page 28.
1 Press HOME MENU.
2 Select “Sound“ (/ then ENTER).
3 Select an item to be adjusted (/).
4 Select the desired level (/).
5 Press HOME MENU to exit the menu.
Note
• You cannot adjust the sound for listening with headphones.
• If you perform sound adjustments with headphones connected,
the new settings will become effective as soon as you disconnect
the headphones.
• To restore the factory defaults for all items, press / to select
"Reset" in step 3, and then press ENTER. A confirmation screen
appears. Press / to select "Yes", and then press ENTER.
FOCUS
This shifts the apparent direction of the sound upward for more clearly
defined sound.
1 Press HOME MENU.
2 Select “Sound“ (/ then ENTER).
3 Select “FOCUS“ (/).
4 Select the desired parameter (/).
5 Press HOME MENU to exit the menu.
Note
• You cannot set up the sound field for listening with headphones.
• If you set up the sound field with headphones connected, the new
setting will become effective as soon as you disconnect the
headphones.
• The effect of this function differs depending on signals.
Front Surround
This provides three-dimensional sound effects and/or deep, rich bass.
1 Press HOME MENU.
2 Select “Sound“ (/ then ENTER).
3 Select “Front Surround“ (/).
4 Select the desired parameter (/).
5 Press HOME MENU to exit the menu.
Item  button  button
Treble For weaker treble For stronger treble
Bass For weaker bass For stronger bass
Balance Shifts the audio balance to the
left
Shifts the audio balance to the
right
Bass
Balance
Reset
FOCUS
Front Surround
0
0
Off
Off
Sound STANDARD
Treble
2
FOCUS
Selections Off Deactivates FOCUS.
On Activates FOCUS.
Front Surround
Selections Off Deactivates both SRS and TruBass
SRS Reproduces highly effective three-dimensional
sound.
TruBass
(default)
Provides deep, rich bass using a new
technology.
TruBass + SRS Provides both TruBass and SRS effects.
Bass
Balance
Treble
Reset
FOCUS
Front Surround
0
0
Off
2
Sound STANDARD
Off
PDP4270XD_En.book Page 32 Friday, June 16, 2006 5:32 PM

Pioneer PDP-4270XD Specifications

General

Depth	115 mm
Width	1040 mm
Height	679 mm
Weight	32100 g
Comb filter	3D
Pixel pitch	- mm
Aspect ratio	16:9
Product color	Black
Noise reduction	Yes
RMS rated power	13 W
Display diagonal	42 \
Channels quantity	99 channels
Display brightness	1100 cd/m²
Display resolution	1024 x 768 pixels
Display technology	Plasma
Power requirements	AC 220 - 240 V, 50/60 Hz
SCART ports quantity	3
Contrast ratio (typical)	3000:1
Analog signal format system	PAL, SECAM
Power consumption (standby)	0.7 W
Power consumption (typical)	291 W
