9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
REED PETAL REMOVAL
NOTICE
The VForce3 reed petal replacement kit, PN 2207948,
includes parts to service 1 reed valve:
• 2 outer reed petals
• 2 inner reed petals
• 2 retainer bars
• Reed valve disassembly tool
1. Insert the supplied reed cage disassembly tool
q
between the reed and reed stop. Push the tool firmly
to release the tabs.
2. Remove the inner cage
w
from the outer flange
e
.
3. Remove and discard the two outer reed petals
r
.
4. Use a small flat-blade screw driver to pry the inner
reed retainers
t
out of the inner cage. Discard the
retainers.
5. Remove and discard the two inner reed petals
y
.
6. Thoroughly clean the inner and outer cages. Do not
reuse if damage is found.
ENGINE / COOLING / EXHAUST
