6.26
9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
6. Install new upper and lower sprocket fasteners with
the original domed washers. Orientate the washer
domes out. Torque fasteners to specification.
TORQUE
Upper / Lower Sprocket Fasteners:
44 ft-lbs (60 Nm) Use new fasteners during
assembly
7. On models with electric start, reinstall the battery
brackets and battery. Verify the battery strap D-clip
does not make contact with the drive belt.
8. Connect the RED (POSITIVE) battery cable first, and
then the BLACK (NEGATIVE) cable.
9. Tip snowmobile back onto it skis. Reinstall the fender.
Reinstall the right side engine compartment door.
FINAL DRIVE / BRAKE SYSTEMS
