5.19
BODY / STEERING / SUSPENSION
5
REAR HOUSING
Exploded View
A. CV Boot Retaining Ring
B. Inner CV Boot
C. Sprocket Hub
D. Bearing (2)
E. Rear Axle Housing
F. O-Ring
G. Rear Brake Disc Hub
H. Brake Hub Retaining Ring
A
B
C
D
E
F
H
G
I
D
A
B
CV Ball/Cage Assembly
Individual Parts Not Available - Order Hub Assembly
