3.12
ENGINE
ES50PL Oil Flow Chart
Oil Tank
Oil Hose
Crankcase (Mag Side)
Oil Gallery
Crankcase (Clutch Side)
Oil Gallery
Oil Pump
(Scavenging)
Oil Hose
Oil Strainer
Crankcase (Mag Side)
Oil Gallery
Crankcase (Clutch Side)
Oil Gallery
Oil Pump
(Feed)
One Way Valve
Bypass
Oil Filter
Delivery Pipe
Oil Shaft
Transmission
Main Shaft
Transmission
Counter Shaft
Crankcase
Cylinder
Piston
Connecting Rod
(Small End)
Large End
Bearing
Crank Pin
Crankshaft
Gears
Gears & Clutch
Gears
Ball Bearing
(Mag Side)
Cam Chain
Cam & Crank Sprocket
Chain Room
Cam Lobe
Valve Lifter
Cam Shaft
Journal
Cam Support
Oil Gallery
Cylinder Head
Oil Gallery
Prevents oil from
draining into
crankcase with
engine off
Indirect
Lubrication
Indirect
Lubrication
Oil Jet
Top of Oil Tank
