5.26
BODY / STEERING / SUSPENSION
5. Disassemble, clean and inspect the upper A-arm bushings
and shaft. Replace components as required.
6. Disassemble, clean and inspect the lower A-arm thrust
washers, needle bearing, seals and shaft. Replace
components as required.
7. Inspect needle bearing performance by rotating the shaft
inside the bearing. If replacement is required, press the
bearings out from opposite sides using a drift punch or other
suitable tool.
Carrier Assembly
1. Assemble and install the upper A-arm bushings and shaft.
2. Install needle bearings by pressing the bearings into the
housing using a suitable tool.
3. Apply grease and install the shaft. Install the lower A-arm
seals.
Seal
Needle Bearing
Shaft
Thrust
Washer
Bearing Removal
Bearing Installation
Seal
Thrust
Washer
Shaft
