5 – Managing Ports
Port Information Data Window
59264-02 A 5-3
A
Operational Port State The port state that is currently active. This
value may be different from the adminis-
trative port state, for example due to an
error condition.
Configured Administrative Port State The port state (Online, Offline, Diagnos-
tics, or Down) which is saved in the switch
configuration, either by the user or at the
factory. This value is persistent; it will be
maintained during a switch reset, and will
be used after a reset to set the port opera-
tional state.
Logged In Indicates whether logged in or not.
Port Connection Status E_Port connection status. Status can be
None, Connecting, Connected or Isolated.
Reason of Status Why E_Port is isolated.
Administrative Port Speed The speed requested by the user.
Operational Port Speed The speed actually being used by the port.
Port Speed Supported The speeds supported by the port
Symbolic Name Port symbolic name
POST Status Status from the most recent Power On Self
Test
POST Fault Code Fault code from the most recent Power On
Self Test
Test Status Status from the most recent port test
Test Fault Code Fault code from the most recent port test
Advanced Group
MFS Mode Multiple Frame Sequence bundling status.
Configured I/O Stream Guard The requested RSCN message suppres-
sion status by the user. Status can be
enabled, disabled, or automatically deter-
mined by the switch.
Operational I/O Stream Guard The actual RSCN message suppression
status. Status can be enabled, disabled, or
automatically determined by the switch.
Table 5-1. Port Information Data Window Entries (Continued)
Entry Description
