Quantum LTO-9 HH SAS User Manual

Chapter 4: Operations
Diagnostic and Maintenance Functions
Quantum LTO-9 HH SAS User’s Guide 57
3 Press the Unload button, then release it to view the most recent
error code.
4 Press and release the Unload button again to view successive error
codes. Let two to three seconds pass between each depression. The
Ready light and Fault light will flash On/Off once for each
successive error code. The SCD will display 0 when all the error
codes have been displayed.
5 After viewing all error codes, exit this function by pressing the
Unload button again. The SCD will display 0 and exit Maintenance
Mode.
Function Code A: Clear
Error Code Log
Function Code A erases the contents of the error code log.
1 Place the drive in Maintenance Mode. For instructions, see Entering
Maintenance Mode on page 47.
2 Press the Unload button once per second until A appears in the
SCD. (If you cycle past the desired code, press the Unload button
once per second until the code reappears.)
3 Press and hold the Unload button for three or more seconds, then
release it to select the function. A flashes in the SCD, followed by 0.
The tape drive erases all errors from the error code log and exits
Maintenance Mode.
Function Code C: Insert
Cartridge into Tape
Drive
This function cannot be selected by itself, but is part of other
maintenance functions (such as Run Tape Drive Diagnostics and Create
FUP Tape) that require a tape cartridge to be inserted.
Function Code E: Test
Cartridge & Media
Approximate Run Time = 15 minutes per loop
Total Number of Loops = 10
Function Code E performs tests that determine whether a suspect
cartridge and its magnetic tape are acceptable.
Press the Unload button to stop the diagnostic and exit maintenance
mode. Pressing the Unload button once will abort the test at the end of
the current test loop. Pressing the Unload button twice will abort the
