Quantum LTO-9 HH SAS User Manual

Chapter 4: Operations
Diagnostic and Maintenance Functions
Quantum LTO-9 HH SAS User’s Guide 55
error either turn the power off and then on again, or reboot the
drive by pressing and holding the Unload button for 10
seconds.
Function Code 7: Run
RS-422 Wrap Test
Note: This function is described here for information only. It is not
supported on the LTO-6, 7, 8, or 9 Tape Drives.
This test causes the drive to perform a check of the circuitry and
connector for the RS-422 interface. This connector supports the Library
Drive Interface (LDI) and the Automation Drive Interface (ADI).
Before selecting this function, attach an LDI or RS-422 wrap plug to the
drive's LDI or RS-422 connector (in place of the LDI or RS-422 cable).
1 Make sure that no cartridge is in the drive, and the appropriate
wrap plug is attached to the RS-422 connector.
2 Place the drive in Maintenance Mode. For instructions, see Entering
Maintenance Mode on page 47.
3 Press the Unload button once per second until 7 appears in the
Single-character Display (SCD). If you cycle past 7, continue to press
the Unload button until it displays again.
4 To select the function, press and hold the Unload button for three
seconds. After you select the function, 7 flashes and the drive
automatically starts the test.
• If no error is detected, the diagnostic will loop and begin again.
To stop the loop, press the Unload button for one second and
release. When the diagnostic ends, 0 temporarily appears in the
SCD, and the tape drive exits Maintenance Mode.
• If an error is detected, the Fault light flashes and the drive posts
an error code to the SCD. To determine the error, locate the
code in Appendix A,
Error Codes and Messages. To clear the
error either turn the power off and then on again, or reboot the
drive by pressing and holding the Unload button for 10
seconds.
Function Code 8:
Unmake FUP Tape
Function Code 8 erases the firmware update (FUP) data and rewrites
the cartridge memory on the tape. This converts the cartridge into a
valid scratch (blank) data cartridge.
