INTRODUCTION
Harmony Ball Return Manual – 400-254-022 2 Rev. Date 3/16
3.0 PACKING LISTS AND TOOLS
If installing part number 612-300-260, you should receive the following:
Part Number
Description
Quantity
254-001-300
Harmony Ball Lift
1
254-001-181
Harmony Hood-Rack Installation Kit
1
254-001-017
Harmony Rack Pedestal/Hardware Kit
1
254-001-191-XX
Harmony Ball Lift Hood Set*
1
610-494-444
Underlane Track Shim Package
1
612-500-032
Underlane Track Kit¹
1
000-021-185
Underlane Track Plate Weldment¹
1
167-003-122
Plastic Runner Assembly¹
1
612-500-031
Underlane Track Kit²
1
049-006-586
Rail Track Assembly²
1
* ”-XX” at the end of a part number denotes that color options are available.
You will receive either the items with a “1” after them or the items with a “2” after them, depending on what
underlane track is installed.
If installing part number 612-300-262, you should receive the following:
Part Number
Description
Quantity
254-001-080
Lower Ball Rack
1
254-001-119
Lower Ball Rack Hardware Kit
1
Installation Tools
The following is a list of tools needed for the installation of the Harmony Ball Return. Other
tools may be required depending on whether you are installing the unit on a wood or synthetic
approach.
tape measure
straight edge/carpenter’s square
reciprocating saw
3/8” drive ratchet
7/32” & 5/32” Allen wrench or drive
12-inch, 3/8”-drive extension
pencil/marker
7/16”, 1/2”, 5/16”, & 12mm sockets
circular saw
7/16”, 1/2”, 9/16”, 3/4”, & 15/16” combination wrenches
hammer drill
#2 Phillips screwdriver
wire strippers
small flat-head screwdriver
wire cutters
3/16”, 7/32”, 9/32”, & 7/16” drill bits
utility knife
5/16” masonry (carbide tipped) bit
crimpers
level
impact/driver
hammer
1/4" nut driver
