PARTS
Harmony Ball Return Manual – 400-254-022 Rev. Date 3/16 47
254-001-302, Even Side Plate Assembly
Part No.
Description
Qty
1
254-001-304
Even Side Plate
1
2
254-001-327
Top Side Liner
1
3
254-001-328
Middle Side Liner
4
4
254-001-329
Bottom Side Liner
1
5
938-101-015
RVT DRD 0.25 X 0.75 NY BLK
24
