INSTALLATION
Harmony Ball Return Manual – 400-254-022 29 Rev. Date 3/16
6.10 ELECTRICAL RATINGS
The Harmony Ball lift controller, motor, and blower can be configured for 230 VAC or 115 VAC
operation at either 50 or 60 hertz, as described elsewhere in this manual. Always configure all
ball lift electrical components to match the voltage supplied to the machine. Power to the lift
must be installed in accordance with local electrical codes and must be capable of meeting the
following requirements. This unit is designed for indoor use only.
230 VAC operation: single phase, 50 or 60 Hertz, 1.9 Amps
115 VAC operation: single phase, 50 or 60 Hertz, 3.8 Amps
Figure 23, Nameplate Data
Actuators, Motors, and Sensors
