OPERATION
Harmony Ball Return Manual – 400-254-022 32 Rev. Date 3/16
POWER SAVE
 The lift motor runs for 12 seconds when a ball enters the lift.
 Intrusion detection is disabled.
 Blower is enabled.
CONTINUOUS
 The lift motor runs continuously.
 Intrusion detection is disabled.
 Blower is enabled.
MECHANIC’S MODE
 Lift motor and blower are operated by the start and stop buttons.
 Permits troubleshooting of the intrusion sensor.
Holding the MODE SELECT button for more than five seconds will cycle through the various
operating modes. Release the button when the STATUS LED indicates the desired mode.
Replace and secure the hood. The alarm will beep once to indicate the lift is active.
8.3 ERRORS
Figure 24, Control Box Display
Blinking Red
and Green
Red
Blinking Green
