Raymarine G-Series User Manual

10.1GPMprocessorunit
Technicalspecication
Nominalsupplyvoltage12or24Vdc
Operatingvoltagerange
10.7to32Vdc
Fuse/Breakers
12Vsupply:
•10Afuseprotectionatdistribution
panel.
•10Athermalcircuitbreaker
protectionatdistributionpanel.
24Vsupply:
•4Afuseprotectionatdistribution
panel.
•10Athermalcircuitbreaker
protectionatdistributionpanel.
TypicalpowerconsumptionNoexternalloads:
•3Aat12V
•1.5Aat24V
Withexternalloads:
•5Aat12V
•2.5Aat24V
EnvironmentalInstallationenvironment
•Operatingtemperature:-15ºCto
+55ºC(5ºFto131ºF)
•Non-operatingtemperature:-25ºC
to+70ºC(–13ºFto158ºF)
•Relativehumiditylimit:80%
•Waterprotection:dripresistant
whenmountedvertically.
Storageconditionsforpackagedunit•Temperature:-25ºCto+55ºC
(–13ºFto131ºF)
•Relativehumidity:75%
Dimensions
•Width:335mm(13.19in)
•Height:230mm(9.06in)
•Depth:125mm(4.92in)
Weight
6.5kg(14.33lb)
Dataconnections
•NMEA0183ports(quantity:2):
•SeaTalk
•SeaTalk
hs
•SeaTalk
ng
•CompactFlash
•USB(softwareupgradeonly)
148G-Seriesinstallationinstructions
