NMEA0183cables
CablesforconnectingNMEA0183devicestotheG-Seriessystem.
CablePartnumberNotes
1.5m(4.9ft)NMEA
0183cable
R08004
SuppliedwiththeGPM
processorunit.
OtherNMEA
connections
—
Refertodealerfor
suitablecables.
Note:Anynon-Raymarinecablesmustuseashieldedtwisted
paircabletominimiseinterference.
3.10NMEA2000connection
ThesystemcanreceivedatafromNMEA2000devices(forexample,
datafromcompatibleengines).TheNMEA2000connectionis
madeusingSeaTalk
ng
andappropriateadaptorcables.
D118 33 -1
2
4
1
3
1.SeaTalk
ng
backbone.
2.SeaTalk
ng
toDeviceNetadaptorcable.
3.NMEA2000connection.
4.Enginegatewayorengineconnection.
Cablesandconnections
71
