Raymarine G-Series User Manual

Videooutputresolutions
2xDVIvideooutputs(orVGAwith
adaptorcable),bothofwhichsupport
thefollowingresolutions:
•1024X768
•1280X720
•1280X768
•1280X800
•1280X1024
SeaTalk/alarmpoweroutput
250mAat12V
Videooutput
DVI(quantity:2).OptionalVGA
adaptoravailable.
Audiooutput
Stereolineout(rated1VRMS)
Conformance•89/336/EECasamendedby
92/31/EEC
•EN60945:2002
10.2GVM400videomodule
Technicalspecication
Nominalsupplyvoltage12or24Vdc
Operatingvoltagerange
10.7to32Vdc
Fuse/Breakers
12Vsupply:
•2Afuseprotectionatdistribution
panel.
•1.2Athermalcircuitbreaker
protectionatdistributionpanel.
24Vsupply:
•1Afuseprotectionatdistribution
panel.
•1Athermalcircuitbreaker
protectionatdistributionpanel.
Typicalpowerconsumption•650mAat12V
•330mAat24V
EnvironmentalInstallationenvironment
•Operatingtemperature:-15ºCto
+55ºC(5ºFto131ºF)
•Non-operatingtemperature:-25ºC
to+70ºC(–13ºFto158ºF)
•Relativehumiditylimit:80%
•Waterprotection:dripresistant
whenmountedvertically.
Technicalspecication
149
